Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power System

Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power System
Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power System Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power System

Large Image :  Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power System

Product Details:
Place of Origin: China
Brand Name: KUOMAN
Model Number: JST-EXMH-(200-210)W
Payment & Shipping Terms:
Minimum Order Quantity: 1 Container
Price: based on quantity
Packaging Details: 1425*1100*885mm
Payment Terms: T/T
Supply Ability: 2000 pcs/month
Contact Now

Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power System

Description
Maximum Power: 210W Open Circuit Voltage: 21.96V
Short Circuit Current: 11.58A Voltage At Pmax: 19.06V
Current At Pmax: 11.02A Module Efficiency: 20.01%
Power Tolerance: 0 ~ +4.99W Maximum System Voltage: 700Vdc
Max Series Fuse: 15A Temperature Coefficient: -0.350%/°C
Highlight:

light-weight 10.87kg solar panel

,

210W MC4 PV panel

,

marine power system solar panel

Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power System
Product Overview

With best-in-class efficiency of 20.01% (210W model), it delivers maximum power output while maintaining a compact footprint. Ideal for users seeking to minimize installation space without compromising energy generation.

Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power System

Technical Specifications
Parameter 200W Model 210W Model
Maximum Power (Pmax) 200W 210W
Open Circuit Voltage (Voc) 21.79V 21.96V
Short Circuit Current (Isc) 11.24A 11.58A
Voltage at Pmax (Vmp) 18.76V 19.06V
Current at Pmax (Imp) 10.66A 11.02A
Module Efficiency 19.01% 20.01%
Power Tolerance 0 ~ +4.99W 0 ~ +4.99W
Maximum System Voltage 700Vdc (IEC/UL) 700Vdc (IEC/UL)
Max Series Fuse Rating 15A 15A
Key Features & Benefits
  • Unmatched Efficiency & Power Density - 20.01% module efficiency (210W) generates more electricity per square meter than competing panels. High power output (210W) in compact size (1375 * 765 * 30mm) maximizes roof or ground space.
  • Superior Temperature Performance - Low temperature coefficient (-0.350%/°C for Pmax) ensures minimal power loss in hot climates.
  • Industrial-Grade Durability - IP67 junction box (waterproof to 1m for 30 minutes) and 3.2mm tempered glass resist moisture, dust, and impact. 5400Pa front wind load / 2400Pa rear snow load rating for harsh environmental resilience.
  • Scalable & Future-Proof - 700V system voltage supports large series connections for utility-grade or industrial systems. Customizable cable lengths (90cm standard) and MC4 compatibility simplify complex PV array integration.
Frequently Asked Questions

Q1: What is the peak power range for this solar panel?

A: This monocrystalline PV module provides 200W‑210W maximum peak power under STC standard test conditions.

Q2. What are the dimension and net weight?

A: External size 137576530 mm, net weight 10.87 kg for one piece.

Q3. Is the junction‑box waterproof?

A: Yes, it is equipped with an IP67 waterproof‑grade junction box for full dust‑proof and water‑resistant performance.

Q4. Can I customize the length of the output cables?

A: Sure. The default cable length is 90cm, and we support custom cable lengths on request. It adopts MC4 compatible solar panel connectors.

Q5. What extreme weather can the solar panel endure?

A: It withstands 5400Pa front snow load and 2400Pa rear wind load. Its safe operating temperature spans ‑40℃ to +85℃.
Light‑Weight 10.87KG 200W‑210W Solar Panel, Easy‑Install MC4 PV Panel For Caravan & Marine Power SystemApplication Scenarios
Large Off-Grid Homes
Primary power for remote cabins, farms, or eco-resorts
Commercial Rooftops
Small businesses, warehouses, or agricultural facilities seeking energy independence
Telecom & Utilities
Powers remote cell towers, weather stations, or grid-tied backup systems
Mobile Applications
Heavy-duty RV solar systems, large boats, or mobile command centers
