40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam

40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam
40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam 40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam

Large Image :  40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam

Product Details:
Place of Origin: China
Brand Name: Kuoman
Certification: CE, FCC, UKCA, CB
Model Number: KM500-600W Solar Panel
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD1-100/pcs
Packaging Details: standard international carton packing
Delivery Time: general two weeks, more quantity based on exact quantity
Payment Terms: T/T
Supply Ability: 10000pcs/month
Contact Now

40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam

Description
Panel Efficiency: 22% Panel Dimensions: 1903x1134x35mm
Voltage: 24 Volts Current: 12.5 Amps
Weather Resistance: IP65 Material: Tempered Glass, Aluminum Frame, Silicon Cells
Short Circuit Current: 13.88-14.22A Junction Box: 25A, IP68
Cell Count: 144 Monocrystalline Cell Dimensions: 166x83mm
Encapsulation Material: EVA Celltype: Monocrystalline / Polycrystalline Silicon
Max System Voltage: 1000V/1500V DC Module Dimension: 1722x1134x30mm
Cells: 144 Monocrystalline
Highlight:

40W monocrystalline solar panel for boat

,

marine power solar panel with warranty

,

solar panel for yard lamp

40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam

40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam

Product Specification:

Our 40W monocrystalline PV solar panel comes with 28 high‑efficiency mono solar cells, delivering stable 40‑watt power output for off‑grid power needs. Sized 58039525mm and weighing only 2.55 kg, this compact‑sized solar module is lightweight for easy mounting, transport and outdoor installation. Built‑to‑withstand harsh outdoor weather, it is a budget‑friendly energy solution for residential yards, cabins, outdoor equipment and remote off‑grid systems.

Electrical Characteristics (STC):

  • Maximum Power (Pmax): 40W
  • Open Circuit Voltage (Voc): 19.12V
  • Short-Circuit Current (Isc): 2.55A
  • Voltage at Pmax (Vmp): 16.53V
  • Current at Pmax (Imp): 2.42A
  • Maximum System Voltage: 700V DC
  • Power Tolerance: 0 to +4.99W

Mechanical Specifications:

  • Dimensions: 580 x 395 x 25 mm
  • Weight: 2.5 kg
  • Solar Cells: Monocrystalline 182mm (28 cells, 2x14 configuration)
  • Frame: Anodized Aluminum Alloy
  • Front Glass: 3.2mm Tempered Glass
  • Junction Box: IP67 rated, with 50cm output wires (custom length available) and MC4-compatible connectors.
  • Mechanical Load Capacity: 5400Pa (Front) / 2400Pa (Rear)

Temperature & Operational Ratings:

  • Operating Temperature: -40°C to +85°C
  • Nominal Operating Cell Temperature (NOCT): 45±2°C
  • Pmax Temperature Coefficient: -0.35%/°C

Packaging:

  • 80pcs per pallet (Pallet Dims: 630x1100x930mm, ~235kg).

40W Monocrystalline Solar Panel For Boat Marine Power, Yard Lamp And Surveillance Cam

Ideal Application Scenarios

  • ackyard & garden outdoor lighting systems
  • 12‑volt battery charging for garden fences, farm gates
  • RV, camper, trailer and boat small‑size off‑grid power supply
  • Remote shed, cabin, chicken coop and greenhouse electricity
  • Security cameras, water pumps, outdoor WiFi and street lights
  • Emergency home backup power and camping portable solar power
  • Pet house, pool equipment and all kinds of low‑voltage outdoor appliances


Frequently Asked Questions


Q1: What battery can this 40W solar panel charge?

A: It works perfectly for charging 12V lead‑acid, lithium and deep‑cycle batteries, matched with a suitable solar charge controller.

Q2. Can I install the solar panel outside in all‑weather conditions?

A: Yes. The aluminum frame, tempered glass and IP67 junction box are engineered for long‑term outdoor use against rain, snow and UV rays.

Q3. How many amps does the 40‑watt solar panel produce?

A: Its optimum operating current reaches 2.42A under standard test conditions (STC:1000W/㎡,25℃).

Q4. Am I allowed to connect multiple 40W panels together?

A. Absolutely. Wire panels in series for higher voltage or parallel for bigger charging current for your power system.

Q5. Does the package include a solar charge controller?

A. This listing is only for the 40W monocrystalline solar panel. You can buy our matching 12V solar controller separately.
