Product Details:
|
| Cell Type: | Monocrystalline PERC 210mm | Number Of Cells: | 132 (6x22) Half-Cut |
|---|---|---|---|
| Module Dimensions: | 2384 X 1303 X 35mm | Weight: | 34.5 Kg |
| Front Glass: | 3.2mm High Transmission Tempered | Frame: | Reinforced Anodized Aluminum |
| Junction Box: | IP68, 3 Diodes | Connector: | MC4-Evo2 Compatible |
| Maximum System Voltage: | 1500V DC | Operating Temperature: | -40degC ~ +85degC |
| Highlight: | 700W monocrystalline solar panel,210mm utility scale solar cells,high power solar panel with warranty |
||
The KUOMAN KS-700M-210 is a flagship utility-grade solar panel delivering an impressive 700W maximum power output. Built with 210mm large-format monocrystalline cells and advanced half-cut architecture, this module dramatically reduces the number of panels, racking, and labor required for large-scale solar farm installations, directly lowering Balance of System (BOS) costs.
| Parameter | Specification |
|---|---|
| Maximum Power (Pmax) | 700W |
| Module Efficiency | 22.1% |
| Open Circuit Voltage (Voc) | 48.9V |
| Short Circuit Current (Isc) | 18.5A |
| Cell Size | 210 x 105mm (Half-Cut) |
| Snow Load | 5400 Pa |
| Wind Load | 2400 Pa |
Contact KUOMAN for utility-scale pricing on 700W solar panels. Volume discounts available.
