High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance

High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance
High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance

Large Image :  High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance

Product Details:
Place of Origin: China
Brand Name: Kuoman
Model Number: Customized Solar Panel
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD1-100/pcs
Packaging Details: standard international carton packing
Delivery Time: general two weeks, more quantity based on exact quantity
Payment Terms: L/C, L/C
Supply Ability: 10000pcs/month
Contact Now

High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance

Description
Panel Efficiency: 22% Current: 12.5 Amps
Cell Type: Monocrystalline/Polycrystalline Weather Resistance: IP65
Maximum Power: 410W-430W Operating Temperature: -40°C To +85°C
Highlight:

IP65 Solar Panel

,

Reinforced Aluminum Frame Solar Panel

,

High Performance Photovoltaic Panel

Industrial High Performance Solar Panel IP65 With Reinforced Aluminum Frame Solar Clean Energy
High-Performance Solar Panel with Reinforced Aluminum Frame
Our industrial-grade solar panel is engineered for utility-scale projects and demanding commercial environments across the Americas and Africa. Featuring a mechanically reinforced, high-strength aluminum alloy frame, it is certified to withstand severe wind loads (up to 2400 Pa) and heavy snow accumulation (up to 5400 Pa). Designed for resilience, it operates reliably in a vast temperature range from -40°C to +85°C, making it a robust solution for diverse climates—from Canadian winters to African deserts.
High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance 0 High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance 1
Standard Test Conditions (STC) Performance Data
Parameter 410W 415W 420W 425W 430W
Maximum Power (Pmax) 410W 415W 420W 425W 430W
Maximum Power Voltage (Vmp) 31.13V 31.32V 31.51V 31.70V 31.88V
Maximum Power Current (Imp) 13.17A 13.25A 13.33A 13.41A 13.49A
Open-circuit Voltage (Voc) 37.73V 37.92V 38.11V 38.30V 38.49V
Short-circuit Current (Isc) 13.91A 13.99A 13.99A 14.15A 14.23A
Module Efficiency STC (%) 21.00 21.25 21.51 21.76 22.02
STC Conditions: Irradiance 1000W/m², cell temperature 25℃, AM1.5G
High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance 2 High Performance Solar Panel with Reinforced Aluminum Frame and IP65 Weather Resistance 3
Technical Specifications
Maximum Power (Pmax) [Insert Wattage, e.g., 550W]
Cell Type & Count 108 Large-Format Monocrystalline
Frame Material Reinforced, Anodized Aluminum Alloy
Mechanical Load Rating Wind: 2400 Pa / Snow: 5400 Pa
Operating Temperature -40°C to +85°C
Temperature Coefficients Pmax: -0.39%/°C; Voc: -0.29%/°C; Isc: +0.033%/°C
Max System Voltage 1500V DC
Series Fuse Rating 15A
Junction Box IP68, Bypass Diode Integrated
Connectors MC4 Compatible
Key Certifications TUV, IEC 61215/61730, UL (Region-Specific)
Why Leading Energy Companies & Contractors Choose Us
For energy firms, municipal projects, and engineering procurement contractors, reliability and total cost of ownership are paramount. We deliver:
  • Certified Structural Integrity: Third-party tested (TUV) for mechanical load and electrical safety, providing verifiable peace of mind for project financiers and insurers.
  • Superior Energy Yield in Heat: Our superior temperature performance translates to more kilowatt-hours generated per peak kilowatt installed compared to conventional panels, especially in high-temperature markets.
  • Global Compliance & Supply Assurance: Products meet international standards (IEC, UL) relevant for the Americas and Africa. We offer scalable supply and logistics support tailored for large projects and distributor partnerships.
  • Dedicated Technical Support: We provide direct engineering support for system design and load analysis, helping integrators and EPCs optimize their installations.
Frequently Asked Questions
How does the wind and snow load rating benefit my project?
High load ratings mean reduced risk of structural failure and lower insurance premiums. They allow for fewer mounting attachments in some designs, potentially lowering installation costs while ensuring compliance with strict local building codes in hurricane-prone or heavy snowfall regions.
Why is a low-temperature coefficient important?
Solar panels operate hotter than ambient air. A lower power temperature coefficient (like our -0.39%/°C) means the panel loses less efficiency on hot days. This results in a higher annual energy yield compared to panels with a standard coefficient, improving your project's financial returns.
Are these panels suitable for integration with energy storage systems?
Absolutely. The stable high-voltage output and robust performance across temperatures make them an excellent, predictable energy source for charging battery systems, both for large-scale commercial storage and off-grid hybrid applications.
What support do you offer for distributors and large-scale EPCs?
We provide comprehensive packages including technical data for system design, CAD files, branded marketing collateral, and flexible logistics options. For EPCs, we offer dedicated project management and volume-based pricing to ensure your project stays on time and on budget.
