Industry Power Solar Panel , Producing Solar Panels 500W-600W

Industry Power Solar Panel , Producing Solar Panels 500W-600W
Industry Power Solar Panel , Producing Solar Panels 500W-600W Industry Power Solar Panel , Producing Solar Panels 500W-600W Industry Power Solar Panel , Producing Solar Panels 500W-600W

Large Image :  Industry Power Solar Panel , Producing Solar Panels 500W-600W

Product Details:
Place of Origin: China
Brand Name: Kuoman
Model Number: KM500-600W Solar Panel
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD1-100/pcs
Packaging Details: standard international carton packing
Delivery Time: general two weeks, more quantity based on exact quantity
Payment Terms: L/C, L/C
Supply Ability: 10000pcs/month
Contact Now

Industry Power Solar Panel , Producing Solar Panels 500W-600W

Description
Panel Efficiency: 22% Panel Dimensions: 1903x1134x35mm
Name: Power Solar Panel Voltage: 24 Volts
Size: 60 X 40 Inches Type: Photovoltaic
Power Output: Customized Current: 12.5 Amps
Inverter Compatibility: Micro-inverter, String Inverter Certifications: UL, CE, TUV
Material: Silicon Weather Resistance: IP65
Warranty: 25 Years Color: Blue Or Black
Highlight:

Industry Power Solar Panel

,

Producing Solar Panels 500W

,

Producing Solar Panels 600W

500-600W Customized popular Solar Power Panel



KUOMAN Solar Panel Details:

Industry Power Solar Panel , Producing Solar Panels 500W-600W 0Industry Power Solar Panel , Producing Solar Panels 500W-600W 1Industry Power Solar Panel , Producing Solar Panels 500W-600W 2Industry Power Solar Panel , Producing Solar Panels 500W-600W 3Industry Power Solar Panel , Producing Solar Panels 500W-600W 4



MECHANICAL CHARACTERISTICS
Dimensions: 2108x1048x35mm(LxWxH)
Weight: 25kg
Front Glass: 3.2mm high transmisson tempered glass
Encapsulation: EVA
Cells: 144pcs 166x83mm Monocrystalline solar cells
Backsheet: Composite film
Frame: Anodized aluminum profile
Junction Box: Rated current:25A,IP68,TUV
Cable: Length Negative 400mm/Positive 300mm
Connector: Compatible with MC4

PACKAGING CONFIGURATION
  • Container type:​ 40HQ
  • No. of modules per container:​ 726
  • No. of modules per pallet:​ 31
  • No. of pallets per container:​ 20
  • Packaging box size (LxWxH):​ 2130x1145x1170 (mm)
  • Box gross weight:​ 775 (kg)

Industry Power Solar Panel , Producing Solar Panels 500W-600W 5



Industry Power Solar Panel , Producing Solar Panels 500W-600W 6





Operating Conditions
Maxi System Voltage
1000V/1500V DC
Temperature range
-40°C~+85°C
Series Fuse Rating
15A
NOTC
45±2℃
Temperature Coefficient of Isc(α-Isc)
+0.033%/℃
Temperature Coefficient of Voc(β-Voc)
-0.29%/℃
Temperature Coefficient of Pmax(Y-Pmp)
-0.39%/℃



Packing:
Normally packing: 1pc/2pcs/5pcs/10pcs/25pcs per carton/pallet
Individual packing requirement is acceptable.



Shipping:
Material in stock can be produced (procedure 5-20days) right away after pre-payment confirmation.
We will find the most suitable and safe mode of transportation,don't worry about package damage or loss. It takes about 7~15 working days to worldwide.
Please note us your contact details include your phone number for easy contacting from shipping company officer.

Shipping Methods
Arrive AT
Delivery From
By Sea
Sea Port Want
Any port in china
By Air
Specification
Any port in china
By Railway
Your door
Any railway station
By express
Specification
Zhengzhou City



KUOMAN Case:



Industry Power Solar Panel , Producing Solar Panels 500W-600W 7

Industry Power Solar Panel , Producing Solar Panels 500W-600W 8

Industry Power Solar Panel , Producing Solar Panels 500W-600W 9
