Product Details:
|
| Output Type: | Single Phase Or Split Phase | Output Power: | 10KW 10KVA 10000W |
|---|---|---|---|
| Input Voltage: | 12V/24V/48V | Weight: | 14Kgs |
| Output Voltage: | 110V/220V/230V/240V | Output Frequency: | 50Hz/60Hz |
| Rated Output Power: | 10200W / 10200VA | Maximum Efficiency: | Up To 98% |
| Solar Input: | Dual MPPT Trackers (Max 5400W + 5400W) | Battery Voltage: | 48V Nominal |
| Maximum Solar Charging Current: | 160A | AC Output: | Pure Sine Wave (220/230/240VAC) |
| Highlight: | 8.2kW solar inverter for home,grid-tie solar inverter with storage,residential solar energy storage inverter |
||
| Parameter | Specification |
|---|---|
| Rated Output Power | 10200W / 10200VA |
| Maximum Efficiency | Up to 98% |
| Solar Input | Dual MPPT trackers (Max 5400W + 5400W) |
| Battery Voltage | 48V nominal |
| Maximum Solar Charging Current | 160A |
| AC Output | Pure sine wave (220/230/240VAC) |
| Communication Options | RS485, WiFi, GPRS |
A: It is specially designed for 48V DC battery bank, compatible with lithium batteries, lead-acid batteries, gel batteries and AGM batteries.
A: Yes. Two working modes are switchable. Grid-tie mode feeds surplus solar power back to the grid for credits; off-grid mode works alone during blackouts as a backup power source.
A: Max DC PV open circuit voltage is 500VDC, MPPT working voltage range is 90VDC to 450VDC, with two separate MPPT trackers.
A: Yes. WiFi module is optional, supporting mobile APP real-time viewing of PV generation, battery voltage, load power, grid data and parameter modification.
A: Pure sine wave AC output, same as public grid power. Safe for TVs, computers, air conditioners, refrigerators and all sensitive household electrical devices.
A: Standard 2-year factory warranty, with lifetime technical support and spare parts supply.
