18kW 3 Phase Solar Hybrid Inverter 3 MPPT Trackers Max PV 36000W Off Grid Inverter

Large Image : 18kW 3 Phase Solar Hybrid Inverter 3 MPPT Trackers Max PV 36000W Off Grid Inverter

Product Details:

Place of Origin:	China
Brand Name:	KUOMAN
Certification:	CE UL
Model Number:	Three-Phase Hybrid Grid-Tied Inverter

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	based on specification
Packaging Details:	Standard internationa packing
Delivery Time:	20 working days
Payment Terms:	T/T
Supply Ability:	100pcs/month

Contact Now

18kW 3 Phase Solar Hybrid Inverter 3 MPPT Trackers Max PV 36000W Off Grid Inverter

Description

Battery Voltage:	40-60V DC	Operating Temperature:	-25°C To 60°C
Output Power:	14,000W / 16,000W / 18,000W	MPPT Efficiency:	99.9%
AC Input Range:	110V:85-138VAC;220V:170-275VAC	Efficiency:	95% - 98%
Output Configuration:	Three-phase + Neutral + Ground (3L+N+PE)	Rated Voltage/Frequency:	120/208V, 60Hz
Peak Off-Grid Power:	28kVA To 36kVA	Power Factor:	0.8 Leading To 0.8 Lagging
Maximum PV Voltage:	600V Per Tracker	Protection Rating:	IP65
Highlight:	18kW solar hybrid inverter , 3 phase off grid inverter , 3 MPPT trackers inverter

18kW 3 Phase Solar Hybrid Inverter 3 MPPT Trackers Max PV 36000W Off Grid Inverter

Empower your home or business with the robust and intelligent BSR Series three-phase hybrid inverters. Available in 14kW, 16kW, and 18kW models, these inverters seamlessly integrate solar, grid, and battery storage to provide reliable, efficient, and flexible power management. Featuring a modern white casing with a user-friendly display and easy-grip handles, the BSR series combines advanced technology with practical design.

Technical Specifications & Features

- Dual working mode: Grid-tied on-grid operation + off-grid standalone backup power
- 3 independent MPPT trackers, maximum 99.9% MPPT tracking efficiency
- Wide PV input voltage 120V–500V, max PV open circuit voltage up to 600V
- Dual battery ports, adaptive BMS lithium battery charging strategy
- High charge/discharge current: up to 300A/330A/350A for different models
- 3L+N+PE three-phase grid connection, 120/208V 60Hz standard output
- Power factor adjustable from 0.8 leading to 0.8 lagging, THD＜3% for clean sine wave output
- Grid & generator dual AC input, 200A bypass overload current capacity
- Parallel expansion support: 1–9 units parallel for larger power demand
- IP65 dustproof & waterproof rating, intelligent air cooling + heat sink heat dissipation
- Multiple communication ports: RS485, CAN, USB, optional WiFi/4G remote monitoring module
- Complete electrical protection & full international certifications

Ideal Application Scenarios

Residential Homes with 3-Phase Supply: Power large homes, HVAC systems, and electric vehicle chargers efficiently

Commercial & Retail Stores: Reduce operating costs by powering lighting, refrigeration, and office equipment with solar energy

Small & Medium Enterprises (SMEs) / Workshops: Run machinery and production equipment reliably with clean, three-phase power

Agricultural & Farming Operations: Power irrigation systems, barns, and processing equipment

Off-Grid & Backup Power Systems: Provide critical power backup for buildings during grid outages
