Three Phase Hybrid Solar Inverter BSR-14K-U3P Off-Grid Grid-Tied Energy Storage Inverter

Large Image : Three Phase Hybrid Solar Inverter BSR-14K-U3P Off-Grid Grid-Tied Energy Storage Inverter

Product Details:

Place of Origin:	China
Brand Name:	KUOMAN
Certification:	CE UL
Model Number:	Three-Phase Hybrid Grid-Tied Inverter

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	based on specification
Packaging Details:	Standard internationa packing
Delivery Time:	20 working days
Payment Terms:	T/T
Supply Ability:	100pcs/month

Contact Now

Three Phase Hybrid Solar Inverter BSR-14K-U3P Off-Grid Grid-Tied Energy Storage Inverter

Description

Battery Voltage:	40-60V DC	Operating Temperature:	-25°C To 60°C
Output Power:	14,000W / 16,000W / 18,000W	MPPT Efficiency:	99.9%
AC Input Range:	110V:85-138VAC;220V:170-275VAC	Efficiency:	95% - 98%
Output Configuration:	Three-phase + Neutral + Ground (3L+N+PE)	Rated Voltage/Frequency:	120/208V, 60Hz
Peak Off-Grid Power:	28kVA To 36kVA	Power Factor:	0.8 Leading To 0.8 Lagging
Maximum PV Voltage:	600V Per Tracker	Protection Rating:	IP65
Highlight:	Three Phase Hybrid Solar Inverter , Off-Grid Grid-Tied Inverter , Energy Storage Solar Inverter

Three Phase Hybrid Solar Inverter BSR-14K-U3P Off-Grid Grid-Tied Energy Storage Inverter

Empower your home or business with the robust and intelligent BSR Series three-phase hybrid inverters. Available in 14kW, 16kW, and 18kW models, these inverters seamlessly integrate solar, grid, and battery storage to provide reliable, efficient, and flexible power management. Featuring a modern white casing with a user-friendly display and easy-grip handles, the BSR series combines advanced technology with practical design.

Technical Specifications & Features

Power & Electrical Specifications

Rated AC Output Power: 14,000W / 16,000W / 18,000W
Output Configuration: Three-phase + Neutral + Ground (3L+N+PE)
Rated Voltage/Frequency: 120/208V, 60Hz
Peak Off-Grid Power: High surge capacity (28kVA to 36kVA) for starting motors
Power Factor Adjustment: Range from 0.8 leading to 0.8 lagging

Battery Compatibility & Management

Battery Voltage Range: Wide 40-60V DC input
Supported Types: Lead-Acid, Lithium-ion, User-Defined
Lithium Battery Integration: Self-adapting BMS communication for seamless compatibility
High Current Charging/Discharging: Up to 350A (model dependent)
Dual Battery Inputs: Supports connection of two battery banks

Solar (PV) Input & Efficiency

Triple MPPT Trackers: 3 independent Maximum Power Point Trackers with 2 strings each
High PV Voltage: Maximum input voltage of 600V per tracker
High Capacity: Maximum PV array power up to 36kW (for BSR-18K-U3P)
Superior Efficiency: Maximum efficiency of 97.5%, CEC efficiency of 97%, and MPPT tracking efficiency of 99.9%

Grid & Generator Integration

Wide Input Range: Broad grid/generator voltage and frequency range for stable operation
High Bypass Current: Supports up to 200A bypass overload current for reliable grid backup

General Data & Robustness

Scalability: Supports parallel connection of 1 to 9 units for large-scale power needs
Protection Rating: IP65 certified for dust-tight and water-resistant performance
Operating Temperature: Wide range from -25°C to 60°C (with derating above 45°C)
Cooling: Combines heat sinks with intelligent forced air cooling
Communication Ports: Includes RS485, CAN, USB, and Dry Contact
Optional Connectivity: Wi-Fi/4G stick for remote monitoring

Safety & Certifications

Comprehensive Protections: Anti-islanding, PV lightning protection, leakage current detection, insulation monitoring, reverse polarity protection, and surge protection
International Certifications: Complies with CSA, IEC62109, and EN61000 standards

Ideal Application Scenarios

Residential Homes with 3-Phase Supply: Power large homes, HVAC systems, and electric vehicle chargers efficiently

Commercial & Retail Stores: Reduce operating costs by powering lighting, refrigeration, and office equipment with solar energy

Small & Medium Enterprises (SMEs) / Workshops: Run machinery and production equipment reliably with clean, three-phase power

Agricultural & Farming Operations: Power irrigation systems, barns, and processing equipment

Off-Grid & Backup Power Systems: Provide critical power backup for buildings during grid outages
