Product Details:
|
| Nominal Voltage: | 72V | Nominal Capacity: | 100Ah |
|---|---|---|---|
| Nominal Energy: | 7360Wh | Charging Current: | 20A |
| Max Discharging Current: | 250A | Net Weight: | 64kg |
| Highlight: | 8000 Cycles LiFePO4 Battery,72V 100Ah Golf Cart Battery,Customized KM 72V -100Ah Battery |
||
KM Battery Specification:
| Product Model | KM-72V100G |
| Nominal Voltage | 73.6V |
| Nominal Capacity | 100Ah |
| Nominal Energy | 7360Wh |
| Cell Type | LiFePO4 Cell |
| Charging Cut-off Voltage | 84V |
| Standard Charging Current | 20A |
| Max Charging Current | 100A |
| Charging Temperature | 0℃～55℃ |
| Discharging Cut-off Voltage | 57.4V |
| Discharging Current | 100A |
| Max Continuous Discharging Current | 250A |
| Peak Discharging Current (3S) | 400A |
| Discharging Temperature | -20℃~60℃ |
| BMS Protection | Overcharging/over-discharging, Over-voltage/Over-current, Short Circuit/etc |
| Case Material | metal/custom material |
| Terminal | fast plug-in |
| Battery Size | 740*320*259mm |
| Net Weight | 64kg |
| Communication | CAN/RS485/RS232/Bluetooth (optional) |
| Certificate | UN38.3/MSDS/Sea/Air Transport Report/CE/IEC |
| Shipping Method | by Sea/Air/Railway |
| Delivery Time | Qty within 100pcs: 5-12 days |
