Product Details:
|
| Operating Temperature: | -25°C To 60°C | Max Input Current: | 15A - 30A |
|---|---|---|---|
| Inverter Efficiency: | 80% | Output Power: | 3KW, 2KW, 4KW, 3.5KW, 5.5KW, 6KW, 1KW |
| MPPT Efficiency: | 99% | Weight: | 7kg - 12kg |
| Highlight: | IP65 Protection Hybrid Inverter,6KW Output Solar Inverter,WiFi Monitoring Power Inverter |
||
The BSSI-V-GN Series Hybrid Solar Inverter is your intelligent gateway to energy independence. Combining a solar inverter, battery charger, and AC transfer switch in one sleek, teal-and-black unit, it manages power from solar panels, the grid, and batteries seamlessly.
Its prominent circular display provides real-time operational data, while robust safety features like over-temperature, overload, and short-circuit protection ensure reliable operation. This inverter is the core component for a modern, resilient, and cost-saving solar energy system.
| Specification | Details |
|---|---|
| Models | BSSI-V-GN4200 (4200W/4200VA) & BSSI-V-GN6200 (6200W/6200VA) |
| Phase | 1-phase |
| Max PV Input | 6200W / 6500W |
| Max Solar Charging Current | 120A |
| Battery Voltage | 24V DC (4200 model) / 48V DC (6200 model) |
| Grid-Tie & Off-Grid | Functions with or without the grid |
| MPPT Voltage Range | 60-450VDC, maximizing solar harvest |
| Output Waveform | Pure sine wave AC output, safe for all appliances |
| Efficiency | Up to 98% max conversion efficiency (DC/AC) |
| Backup Power | Provides up to 4200W (main load) + secondary load power during outages |
| Communication | RS485/RS232/WIFI/GPRS/Lithium Battery compatibility for smart monitoring |
| Operating Temperature | -10°C to 50°C |
| Certifications | Compliant with EN/IEC safety and EMC standards |
| Warranty | 2 years |
A hybrid inverter can manage power from solar panels, the grid, and a battery bank simultaneously. It can feed solar energy to your home, sell excess to the grid, and charge/discharge batteries. A regular grid-tie inverter only feeds solar power to the grid/house and does not manage batteries for backup.
Yes! In battery mode, it automatically and instantly switches to power essential loads from the batteries when the grid fails, ensuring an uninterrupted power supply for connected circuits.
It is compatible with various battery types, including lead-acid and lithium-ion batteries (via communication interface), offering flexibility for your energy storage setup.
